Need to share a local service? Expose a game server, SSH endpoint, or API without a public IP?

cftunnel provides two tunnel engines in one CLI for every scenario.

Cloud mode (Cloudflare, free HTTP/WS tunneling):

cftunnel quick 3000
# ✔ Tunnel started: https://xxx-yyy-zzz.trycloudflare.com

Relay mode (self-hosted, full TCP/UDP tunneling):

cftunnel quick 25565 --relay
# ✔ Relay tunnel: tcp://localhost:25565 → remote port 25565

Mode comparison

Feature	Cloud mode	Relay mode
Engine	cloudflared (Cloudflare Tunnel)	frpc/frps (frp)
Protocols	HTTP / HTTPS / WebSocket	TCP / UDP / HTTP / all protocols
Requires	Free Cloudflare account	Your own public server
Domain	Random `*.trycloudflare.com` or custom domain	Server IP + port
Encryption	Cloudflare encryption + global CDN	frp token authentication
Cost	Free	Server cost (from about $3/month)
Typical use cases	Web / API / Webhook / preview	Game server / database / SSH / remote desktop
Quick start	`cftunnel quick 3000`	`cftunnel quick 25565 --relay`
System service	`cftunnel install`	`cftunnel relay install`

Both modes are independent and can run at the same time.

⬆ Back to top

Features

Cloud mode (Cloudflare Tunnel):

No-domain mode — cftunnel quick <port> creates a temporary *.trycloudflare.com URL with zero setup.
Access protection — add --auth user:pass to enable password protection through the built-in auth proxy.
Simple workflow — init → create → add → up for a custom-domain tunnel.
Automatic DNS — create CNAME records when adding routes and clean them up on removal.

Relay mode (self-hosted):

All protocols — TCP / UDP / HTTP for game servers, databases, SSH, and remote desktop.
One-command deployment — install with curl | bash or Docker Compose, then connect with relay init.
Quick tunnels — cftunnel quick <port> --relay without pre-configuring rules.

Shared:

Cross-platform — macOS (Intel/Apple Silicon), Linux (amd64/arm64), and Windows (amd64/arm64).
Process management — downloads engine binaries and supports macOS launchd, Linux systemd, and Windows Service.
Self-update — built-in version checks and one-command upgrades.
One-click sharing — --share prints a terminal QR code, copies the URL, and provides a Telegram share link.
Scenario presets — preset frontend/webapp/webhook/homeassistant matches the desktop client's common workflows.
Recent ports — quick starts are remembered locally and can be listed or cleared with history.
Portable mode — place an empty portable file beside the binary to keep config, logs, and binaries local.
Desktop client — cftunnel-app provides a visual GUI.
AI-friendly — bundled Claude Code / OpenClaw Skills let AI assistants manage tunnels directly.

⬆ Back to top

Architecture

cftunnel provides two independent tunnel engines:

Cloud mode — traffic travels through Cloudflare's global CDN and gets HTTPS without a public IP:

localhost:3000 → cftunnel → cloudflared → Cloudflare Edge → public users
                 (manager)    (tunnel)      (global CDN)     (domain access)

Relay mode — traffic travels through your public server and supports all protocols:

localhost:25565 → cftunnel → frpc → your public server (frps) → remote users
                  (manager)   (client) (relay server)             (IP:port access)

cftunnel is the management layer: it handles configuration, process orchestration, and binary downloads without proxying application traffic itself.

⬆ Back to top

Install

One-line install (recommended)

macOS / Linux:

curl -fsSL https://raw.githubusercontent.com/qingchencloud/cftunnel/main/install.sh | bash

Windows (PowerShell):

irm https://raw.githubusercontent.com/qingchencloud/cftunnel/main/install.ps1 | iex

Manual download

Download the binary for your platform from Releases.

Build from source

git clone https://github.com/qingchencloud/cftunnel.git
cd cftunnel && make build

⬆ Back to top

Quick start

Option 1: Quick tunnel (zero configuration)

No account, token, or domain is required:

cftunnel quick 3000
# ✔ Tunnel started: https://xxx-yyy-zzz.trycloudflare.com

Add --auth when you need password protection:

cftunnel quick 3000 --auth admin:secret123

The random URL is temporary and expires when you press Ctrl+C.

Share the generated address with a phone or collaborator in one step:

cftunnel quick 3000 --share       # QR code + clipboard + Telegram link
cftunnel share https://xxx.trycloudflare.com --qr

Common development scenarios are available as presets, and every quick start is remembered in a local history file:

cftunnel preset list
cftunnel preset frontend --share  # 5173, Vite / Webpack
cftunnel preset webhook           # 8080, callback/API debugging
cftunnel history                  # list recent ports
cftunnel history clear            # clear local history

Option 2: Custom domain (Cloudflare)

Requires a Cloudflare account and at least one domain.

Create an API token with Cloudflare Tunnel edit, DNS edit, and zone settings read permissions.
Copy your account ID from the Cloudflare dashboard.

cftunnel init --token <your-token> --account <account-id>
cftunnel create my-tunnel
cftunnel add myapp 3000 --domain app.example.com
cftunnel up
# app.example.com → localhost:3000

Option 3: Relay mode (all protocols)

Requires a public server (any VPS provider works).

Deploy the server as described in Relay server deployment, then configure the client:

cftunnel relay init --server 1.2.3.4:7000 --token abc123
cftunnel relay add minecraft --local 25565 --remote 25565 --proto tcp
cftunnel relay add ssh --local 22 --remote 6022 --proto tcp
cftunnel relay up
cftunnel relay install

Quick Relay tunnels are also available:

cftunnel quick 25565 --relay
cftunnel quick 9987 --relay --proto udp

⬆ Back to top

Relay server deployment

Relay mode uses frps on a public server. Choose one of the following deployment methods.

Method A: SSH remote setup (recommended)

Install the server and configure the client from your workstation:

cftunnel relay server setup --host 1.2.3.4 --user root --key ~/.ssh/id_ed25519
# ✔ SSH connected
# ✔ frps installed and client configured

Password authentication (--password) and a fully interactive mode are supported.

Method B: One-line script

Run this on the public server:

curl -fsSL https://raw.githubusercontent.com/qingchencloud/cftunnel/main/install-relay.sh | bash

The script downloads frps, generates a token, registers a systemd service, and prints the client command.

Method C: Docker Compose

mkdir -p cftunnel-relay && cd cftunnel-relay
curl -fsSLO https://raw.githubusercontent.com/qingchencloud/cftunnel/main/docker/relay-server/docker-compose.yml
curl -fsSLO https://raw.githubusercontent.com/qingchencloud/cftunnel/main/docker/relay-server/frps.toml.example
cp frps.toml.example frps.toml
# Edit frps.toml and set auth.token
docker compose up -d

Open port 7000 and the ports used by your tunnels in the server firewall.

⬆ Back to top

Command reference

Cloud mode

Command	Description
`cftunnel quick <port>`	Quick tunnel with a temporary domain
`cftunnel quick <port> --auth user:pass`	Quick tunnel with password protection
`cftunnel init`	Configure Cloudflare authentication
`cftunnel create <name>`	Create a named Tunnel
`cftunnel add <name> <port> --domain <domain>`	Add a route and create its CNAME
`cftunnel remove <name>`	Remove a route and clean up DNS
`cftunnel list`	List all routes
`cftunnel up / down`	Start or stop cloudflared
`cftunnel status`	Show tunnel status
`cftunnel logs [-f]`	View logs
`cftunnel install / uninstall`	Register or remove the system service
`cftunnel destroy [--force]`	Delete the tunnel, DNS records, and config
`cftunnel reset [--force]`	Reset all local configuration

Relay mode

Command	Description
`cftunnel relay init --server <IP:port> --token <token>`	Configure the Relay server
`cftunnel relay add <name> --local <port> --proto tcp`	Add a TCP rule
`cftunnel relay add <name> --local <port> --proto udp`	Add a UDP rule
`cftunnel relay remove <name>`	Remove a rule
`cftunnel relay list`	List all rules
`cftunnel relay up / down`	Start or stop frpc
`cftunnel relay status`	Show connection status
`cftunnel relay check [rule]`	Check connectivity and latency
`cftunnel relay logs [-f]`	View logs
`cftunnel relay install / uninstall`	Register or remove the system service
`cftunnel relay server install`	Install frps on Linux
`cftunnel relay server setup`	Install frps over SSH
`cftunnel quick <port> --relay`	Quick Relay tunnel
`cftunnel quick <port> --relay --proto udp`	Quick UDP Relay tunnel

Version management

Command	Description
`cftunnel version [--check]`	Show the version or check for updates
`cftunnel update`	Update to the latest version

Command	Description
`cftunnel quick <port> --share`	Start Cloud quick with QR, clipboard, and Telegram link
`cftunnel quick <port> --qr`	Print a terminal QR code
`cftunnel quick <port> --telegram`	Open the Telegram share page
`cftunnel share <public-url>`	Generate sharing information for an existing URL
`cftunnel preset list`	List frontend, Web, Webhook, and Home Assistant templates
`cftunnel preset <name>`	Start a quick tunnel using a preset port
`cftunnel history [clear]`	List or clear recent local ports

⬆ Back to top

Configuration

Configuration is stored at ~/.cftunnel/config.yml:

version: 1

auth:
  api_token: "your-token"
  account_id: "your-account-id"
tunnel:
  id: "tunnel-uuid"
  name: "my-tunnel"
  token: "tunnel-run-token"
routes:
  - name: myapp
    hostname: app.example.com
    service: http://localhost:3000

relay:
  server: "1.2.3.4:7000"
  token: "your-relay-token"
  rules:
    - name: minecraft
      proto: tcp
      local_port: 25565
      remote_port: 25565
    - name: game-voice
      proto: udp
      local_port: 9987
      remote_port: 9987

self_update:
  auto_check: true

self_update.auto_check is enabled by default. Set it to false to disable startup checks; the desktop update center checks both the CLI and desktop client.

⬆ Back to top

Troubleshooting

QUIC connection timeout

Symptom: failed to dial to edge with quic: timeout

Fix: cftunnel v0.6.1+ defaults to HTTP/2 (TCP). Re-register the service with cftunnel uninstall && cftunnel install.

DNS hijacked by fake-IP

Symptom: cloudflared connects to 198.18.0.x.

Fix: add the cloudflared process to your proxy TUN bypass list, or add *.argotunnel.com to the fake-IP filter.

Cloudflare 1033

Symptom: the DNS CNAME points to an old Tunnel ID.

Fix: run cftunnel remove <name> and then cftunnel add to recreate the route.

Cloudflare 530

Symptom: cloudflared is not connected to the Edge.

Fix: run cftunnel logs -f and use the error details to apply the fixes above.

Relay connection failed

Symptom: relay status reports disconnected after relay up.

Checklist:

Run cftunnel relay check to test the server, local service, and remote port.
Confirm frps is running: ssh SERVER "systemctl status frps".
Confirm port 7000 is open in the firewall.
Confirm the token matches with cftunnel relay status.
Review logs with cftunnel relay logs -f.

⬆ Back to top

AI integration

cftunnel bundles AI assistant Skills so Claude Code, OpenClaw, and similar coding agents can manage tunnels directly.

Claude Code

After cloning the repository, Claude Code loads the Skills automatically. For example:

Use cftunnel quick to share my local port 3000 temporarily.
Use cftunnel relay to expose my local port 25565.

⬆ Back to top

Development

make build              # local build
git tag v0.x.0 && git push --tags  # tag pushes trigger a GitHub Actions release

Community

Website: cftunnel.qt.cool
Telegram group: Join the cftunnel community
QQ group: OpenClaw community
Issues: GitHub Issues

License

MIT

Maintained and open-sourced by Qingchen Cloud
